Specification

Battery Type	LiFePO4 battery
Nominal Voltage	48V
Nominal Capacity	80Ah
Discharge Cut-off Voltage	37.5V
Max. Charge Voltage	54.75V
Charge Method	CC/CV
Standard Continuous Discharge Current	0.2C ( 16A )
Max. Continuous Discharge Current	80A
Pulse  Discharge Current	300A(10S)
Short Circuit Protection	YES
Operating Temperature  ( discharge )	-20℃~55℃
Operating Temperature  ( charge )	0℃~45℃
Storage Temperature (<1 month)	-20℃~40℃
Storage Temperature (<6 month)	0℃~30℃
Cycle Life	>2500 times
Communication	CAN / RS485
BMS Functions	Cell Balancing, State of charge
BMS Protections	Cell-Level  voltage, Temperature, Over Voltage, Under           Voltage,Over-current
Dimension	445 x 310 x 250mm  (17.5'' x 12.2'' x 9.8'')
Weight	40kg (88.1 lbs)

Features

·    High compacted and super light weight, 1/3 smaller and 2/3 lighter than lead-acid battery

·    Built-in intelligent BMS, with battery over-voltage, over-current, temperature, short circuit protections

·    Visible battery information of SOC, SOH, voltage, current, temperature

·    Support remote diagnosis

·    Good rate discharge performance

·    Communication: CAN/RS485

·    Battery fault diagnosis

·    Battery fault diagnosis tool is optional

·    More than 2500 times long cycle life

Details



Android APP:   http://www.dt-energy.com/public/upload/app/app_SmartBattery.apk



IOS APP:  https://apps.apple.com/cn/app/dt-smart-battery/id1446858822
